Description
cratos force
the intelligent Speed Control System
C800 is the revolution of the proven C Series of operating tables, which has been known for its quality, stability, and flexibility on the market for more than decades.
From its compact and delicate appearance to its distinctive features, C800 allows more precise positioning and speed control to improve work-flow and safety of patients.
Description
ADVANTAGE
the intelligent Speed Control System
- Patented hydraulic speed control system.
- Interchangeable operating table head and leg section.
- Superior table height total stroke.
- Trend/Reverse Trend asymmetric angle design.
- Numerous positioning memory functions (Wireless tablet limited)
1
Advantage No.1A Dynamic Experience By Innovative Speed Control System:
A Dynamic Experience By Innovative Speed Control System:
Cratos Force
The core of the operating table adopts high-end driving technology, showing precise positioning and speed control.
2
Advantage No.2Resuming Leveling
Resuming Leveling
Position 30% Faster
Cratos Force increases the work efficiency by 30% of Auto-leveling movement and levels the position while urgent surgery needs.
| Specification |
|---|
| Table Length |
| Table Width (without side rails) |
| Table Height (without mattress) |
| Trendelenburg / Reverse Trend |
| Lateral Tilt (L / R) |
| Head Section (Up / Down) |
| Shoulder Section (Up / Down) |
| Back Section (Up / Down) |
| Leg (Up / Down) |
| Leg (Open / 2 plates) |
| Flex / Reflex |
| Weight Capacity |
| C800 | C800K | C800E |
|---|---|---|
| 2,072 mm | ||
| 520 mm | ||
| 600~1,100 mm | ||
| 21° / 31° | 21° / 31° | 31° / 31° (After interchanged) |
| 20° / 20° | ||
| 60° / 90° | ||
| N/A | N/A | N/A |
| 80° / 50° | ||
| 20° / 90° | ||
| 0°~180° | N/A | |
| 230° / 100° | ||
| 454 kg / 1000lbs | ||
| Configuration |
|---|
| Extra Shoulder Section (E) |
| Carbon Fiber Built-In Kidney Elevator (K) 120mm |
| Electrical Sliding Longitudinal 300mm |
| Auto-Leveling |
| C800 | C800K | C800E |
|---|---|---|
| ● | ||
| ● | ||
| ● | ● | ● |
| ● | ● |
